170 Parameters
20.08 Minimum torque1 Defines minimum torque limit 1 for the drive (in percent of the
motor nominal torque). See parameter 20.06 Torq lim sel.
-1600.0 … 0.0% Minimum torque 1. 10 = 1%
20.09 Maximum torque2 Defines the source of maximum torque limit 2 for the drive (in
percent of the motor nominal torque). See parameter 20.06
Torq lim sel.
AI1 scaled 02.05 AI1 scaled (see page 105). 1073742341
AI2 scaled 02.07 AI2 scaled (see page 105). 1073742343
FBA ref1 02.26 FBA main ref1 (see page 109). 1073742362
FBA ref2 02.27 FBA main ref2 (see page 109). 1073742363
D2D ref1 02.32 D2D ref1 (see page 110). 1073742368
D2D ref2 02.33 D2D ref2 (see page 110). 1073742369
PID out 04.05 Process PID out (see page 115). 1073742853
Max torque1 20.07 Maximum torque1 (see page 169). 1073746951
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
20.10 Minimum torque2 Defines the source of minimum torque limit 2 for the drive (in
percent of the motor nominal torque). See parameter 20.06
Torq lim sel.
AI1 scaled 02.05 AI1 scaled (see page 105). 1073742341
AI2 scaled 02.07 AI2 scaled (see page 105). 1073742343
FBA ref1 02.26 FBA main ref1 (see page 109
). 1073742362
FBA ref2 02.27 FBA main ref2 (see page 109). 1073742363
D2D ref1 02.32 D2D ref1 (see page 110). 1073742368
D2D ref2 02.33 D2D ref2 (see page 110). 1073742369
PID out 04.05 Process PID out (see page 115). 1073742853
Neg max torq -20.09 Maximum torque2 (see page 170). 1073746949
Min torque1 20.08 Minimum torque1 (see page 170). 1073746952
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
20.12 P motoring lim Defines the maximum allowed power fed by the inverter to the
motor in percent of the motor nominal power.
0.0 … 1600.0% Maximum motoring power. 10 = 1%
20.13 P generating lim Defines the maximum allowed power fed by the motor to the
inverter in percent of the motor nominal power.
0.0 … 1600.0% Maximum generating power. 10 = 1%
21
21 Speed ref
Speed reference source and scaling settings; motor
potentiometer settings.
21.01 Speed ref1 sel Selects the source for speed reference 1. See also parameter
21.03 Speed ref1 func.
Zero Zero speed reference. 0
AI1 scaled 02.05 AI1 scaled (see page 105). 1073742341
AI2 scaled 02.07 AI2 scaled (see page 105). 1073742343
Freq in 02.20 Freq in (see page 105). 1073742356
No. Name/Value Description FbEq
