ABB ACS850 - Process Variable

206 Parameters
34.14 Load high lim2 Maximum load (current or torque) at point 2 of user load
curve.
0 … 1600% Maximum load at point 2. 1 = 1%
34.15 Load high lim3 Maximum load (current or torque) at point 3 of user load
curve.
0 … 1600% Maximum load at point 3. 1 = 1%
34.16 Load high lim4 Maximum load (current or torque) at point 4 of user load
curve.
0 … 1600% Maximum load at point 4. 1 = 1%
34.17 Load high lim5 Maximum load (current or torque) at point 5 of user load
curve.
0 … 1600% Maximum load at point 5. 1 = 1%
34.18 Load integ time Integration time used in limit supervision whenever enabled
by parameter 34.01/34.02.
0 … 10000 s Integration time. 1 = 1 s
34.19 Load cool time Defines the cooling time. The output of the overload
integrator is set to zero if the load stays continuously below
the upper boundary of the user load curve.
0 … 10000 s Load cooling time. 1 = 1 s
34.20 Underload time Time for the underload function. See parameter 34.02
Underload func.
0 … 10000 s Underload time. 1 = 1 s
35
35 Process variable
Selection and modification of process variables for display as
parameters 04.06 … 04.08.
35.01 Signal1 param Selects a signal to be provided as parameter 04.06 Process
var1.
Speed rpm 01.01 Motor speed rpm (see page 103). 1073742081
Speed % 01.02 Motor speed % (see page 103). 1073742082
Frequency 01.03 Output frequency (see page 103). 1073742083
Current 01.04 Motor current (see page 103). 1073742084
Current % 01.05 Motor current % (see page 103). 1073742085
Tor q u e 01.06 Motor torque (see page 103). 1073742086
Dc-voltage 01.07 Dc-voltage (see page 103). 1073742087
Power inu 01.22 Power inu out (see page 103). 1073742102
Power motor 01.23 Motor power (see page 103). 1073742103
SpRef unramp 03.03 SpeedRef unramp (see page 114). 1073742595
SpRef ramped 03.05 SpeedRef ramped (see page 114). 1073742597
SpRef used 03.06 SpeedRef used (see page 114). 1073742598
Tor q R e f use d 03.14 Torq ref used (see page 115). 1073742606
Process act 04.03 Process act
(see page 115). 1073742851
Proc PID out 04.05 Process PID out (see page 115). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
No. Name/Value Description FbEq
