Additional parameter data 267
Parameter groups 1…9
No. Name Type
Data
length
Range Unit
Update
time
Notes
01 Actual values
01.01 Motor speed rpm REAL 32 -30000…30000 rpm 250 µs
01.02 Motor speed % REAL 32 -1000…1000 % 2 ms
01.03 Output frequency REAL 32 -30000…30000 Hz 2 ms
01.04 Motor current REAL 32 0…30000 A 10 ms
01.05 Motor current % REAL 16 0…1000 % 2 ms
01.06 Motor torque REAL 16 -1600…1600 % 2 ms
01.07 Dc-voltage REAL 32 0…2000 V 2 ms
01.08 Encoder1 speed REAL 32 -32768…32768 rpm 250 µs
01.09 Encoder1 pos REAL24 32 0…1 rev 250 µs
01.10 Encoder2 speed REAL 32 -32768…32768 rpm 250 µs
01.11 Encoder2 pos REAL24 32 0…1 rev 250 µs
01.12 Pos act REAL 32 -32768…32768 rev 2 ms
01.13 Pos 2nd enc REAL 32 -32768…32768 rev 2 ms
01.14 Motor speed est REAL 32 -30000…30000 rpm 2 ms
01.15 Temp inverter REAL24 16 -40…160 % 2 ms
01.16 Temp brk chopper REAL24 16 -40…160 % 2 ms
01.17 Motor temp1 REAL 16 -10…250 °C 10 ms
01.18 Motor temp2 REAL 16 -10…250 °C 10 ms
01.19 Used supply volt REAL 16 0…1000 V 10 ms
01.20 Brake res load REAL24 16 0…1000 % 50 ms
01.21 Cpu usage UINT32 16 0…100 % -
01.22 Power inu out REAL 32 -32768…32768 kW or
hp
10 ms
01.23 Motor power REAL 32 -32768…32768 kW or
hp
2 ms
01.24 kWh inverter INT32 32 0…2147483647 kWh 10 ms
01.25 kWh supply INT32 32 -2147483647 …
2147483647
kWh 10 ms
01.26 On-time counter INT32 32 0…35791394.1 h 10 ms
01.27 Run-time counter INT32 32 0…35791394.1 h 10 ms
01.28 Fan on-time INT32 32 0…35791394.1 h 10 ms
01.29 Torq nom scale INT32 32 0…2147483.647 Nm -
01.30 Polepairs INT32 16 0…1000 - -
01.31 Mech time const REAL 32 0…32767 s 10 ms
01.32 Temp phase A REAL24 16 -40…160 % 2 ms
01.33 Temp phase B REAL24 16 -40…160 % 2 ms
01.34 Temp phase C REAL24 16 -40…160 % 2 ms
01.35 Saved energy INT32 32 0…2147483647 kWh 10 ms
01.36 Saved amount INT32 32 0…21474836.47 - 10 ms
01.37 Saved CO2 INT32 32 0…214748364.7 t 10 ms
01.38 Temp int board REAL24 16 -40…160 °C 2 ms
01.40 Speed filt REAL 32 -30000…30000 rpm 2 ms
01.41 Torque filt REAL 16 -1600…1600 % 2 ms
02 I/O values
02.01 DI status Pb 16 0b00000000 …
0b11111111
-2 ms
02.02 RO status Pb 16 0b0000000 …
0b1111111
-2 ms
02.03 DIO status Pb 16 0b0000000000 …
0b1111111111
-2 ms
