244 Parameters
58.30 Transmit delay Defines the delay time which the slave waits until it sends a
response.
0…65335 ms Transmit delay time. 1 = 1 ms
58.31 Ret app errors Selects whether the drive returns Modbus exception codes or
not.
No No 0
Yes Yes 1
58.32 Word order Defines the order of the data words in the Modbus frame.
MSW LSW Most significant word first, then Least significant word. 0
LSW MSW Least significant word first, then Most significant word. 1
58.35 Data I/O 1 Defines the address of the drive parameter which the Modbus
master accesses when it reads from or writes to the register
address corresponding to Modbus In/Out parameter no. 1.
The Modbus master defines the type of the data (input or
output).
The value is conveyed in a Modbus frame using two 16-bit
words. If the drive parameter is a 16-bit value, the LSW
(Least significant word) conveys the value. If the drive
parameter is a 32-bit value, the next Modbus In/Out
parameter is also reserved.
0…9999 Parameter address. Format: xxyy, where:
xx = parameter group
yy = parameter index
1 = 1
58.36 Data I/O 2 See parameter 58.35.
0…9999 See parameter 58.35.1 = 1
…… … …
58.58 Data I/O 24 See parameter 58.35.
0…9999 See parameter 58.35.1 = 1
64
64 Load analyzer
Peak value and amplitude logger settings. See also section
Load analyzer on page 85.
64.01 PVL signal Selects the signal to be monitored by the peak value logger.
The signal is filtered using the filtering time specified by
parameter 64.02 PVL filt time.
The peak value is stored, along with other pre-selected
signals at the time, into parameters 64.06…64.11.
Parameter 64.03 Reset loggers resets both the peak value
logger and amplitude logger 2. The latest time the loggers
were reset is stored into parameter 64.13.
Speed rpm 01.01 Motor speed rpm (see page 103). 1073742081
Speed % 01.02 Motor speed % (see page 103). 1073742082
Frequency 01.03 Output frequency (see page 103). 1073742083
Current 01.04 Motor current (see page 103). 1073742084
Current % 01.05 Motor current % (see page 103). 1073742085
Tor q u e 01.06 Motor torque (see page 103). 1073742086
Dc-voltage 01.07 Dc-voltage (see page 103). 1073742087
Power inu 01.22 Power inu out (see page 103). 1073742102
Power motor 01.23 Motor power (see page 103). 1073742103
No. Name/Value Description FbEq
