256 Parameters
97.20 PM angle offset Defines an angle offset between the zero position of the
synchronous motor and the zero position of the position
sensor.
Notes:
• The value is in electrical degrees. The electrical angle
equals the mechanical angle multiplied by the number of
motor pole pairs.
• This parameter is valid only for permanent magnet motors.
0…360° Angle offset. 1 = 1°
99
99 Start-up data
Language selection, motor configuration and ID run settings.
99.01 Language Selects the language of the control panel displays.
Note: Not all languages listed below are necessarily
supported.
English English. 0809 hex
Deutsch German. 0407 hex
Italiano Italian. 0410 hex
Español Spanish. 040A hex
Nederlands Dutch. 0413 hex
Français French. 040C hex
Dansk Danish. 0406 hex
Svenska Swedish. 041D hex
Russki Russian. 0419 hex
Polski Polish. 0415 hex
Türkçe Turkish. 041F hex
Chinese Chinese. 0804 hex
Serbian Serbian. 081A hex
99.04 Motor type Selects the motor type.
Note: This parameter cannot be changed while the drive is
running.
AM Asynchronous motor. Three-phase AC induction motor with
squirrel cage rotor.
0
PMSM Permanent magnet motor. Three-phase AC synchronous
motor with permanent magnet rotor and sinusoidal BackEMF
voltage.
1
SynRM Synchronous reluctance motor. Three-phase AC
synchronous motor with salient pole rotor without permanent
magnets.
2
No. Name/Value Description FbEq
