Parameters 201
32.04 Delay time Defines the time that the drive will wait after a fault before
attempting an automatic reset. See parameter 32.01
Autoreset sel.
0.0 … 120.0 s Resetting delay. 10 = 1 s
33
33 Supervision
Configuration of signal supervision. See also section Signal
supervision on page 84.
33.01 Superv1 func Selects the mode of supervision 1.
Disabled Supervision 1 not in use. 0
Low When the signal selected by parameter 33.02 Superv1 act
falls below the value of parameter 33.04 Superv1 lo, bit 0 of
06.13 Superv status is activated. To clear the bit, the signal
must exceed the value of parameter 33.03 Superv1 hi.
1
High When the signal selected by parameter 33.02 Superv1 act
exceeds the value of parameter 33.03 Superv1 hi, bit 0 of
06.13 Superv status is activated. To clear the bit, the signal
must fall below the value of parameter 33.04 Superv1 lo.
2
Abs Low When the absolute value of the signal selected by parameter
33.02 Superv1 act falls below the value of parameter 33.04
Superv1 lo, bit 0 of 06.13 Superv status is activated. To clear
the bit, the absolute value of the signal must exceed the value
of parameter 33.03 Superv1 hi.
3
Abs High When the absolute value of the signal selected by parameter
33.02 Superv1 act exceeds the value of parameter 33.03
Superv1 hi, bit 0 of 06.13 Superv status is activated. To clear
the bit, the absolute value of the signal must fall below the
value of parameter 33.04 Superv1 lo.
4
33.02 Superv1 act Selects the signal to be monitored by supervision 1. See
parameter 33.01 Superv1 func.
Speed rpm 01.01 Motor speed rpm (see page 103). 1073742081
Speed % 01.02 Motor speed % (see page
103). 1073742082
Frequency 01.03 Output frequency (see page 103). 1073742083
Current 01.04 Motor current (see page 103). 1073742084
Current % 01.05 Motor current % (see page 103). 1073742085
Torque 01.06 Motor torque (see page 103). 1073742086
Dc-voltage 01.07 Dc-voltage (see page 103). 1073742087
Power inu 01.22 Power inu out (see page 103). 1073742102
Power motor 01.23 Motor power (see page 103). 1073742103
SpRef unramp 03.03 SpeedRef unramp (see page 114). 1073742595
SpRef ramped 03.05 SpeedRef ramped (see page 114). 1073742597
SpRef used 03.06 SpeedRef used (see page 114). 1073742598
TorqRef used 03.14 Torq ref used (see page 115). 1073742606
Process act 04.03 Process act (see page 115). 1073742851
Proc PID out 04.05 Process PID out (see page 115). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
No. Name/Value Description FbEq
