202 Parameters
33.03 Superv1 hi Selects the upper limit for supervision 1. See parameter 33.01
Superv1 func.
-32768.00 …
32768.00
Upper limit for supervision 1. 100 = 1
33.04 Superv1 lo Selects the lower limit for supervision 1. See parameter 33.01
Superv1 func.
-32768.00 …
32768.00
Lower limit for supervision 1. 100 = 1
33.05 Superv2 func Selects the mode of supervision 2.
Disabled Supervision 2 not in use. 0
Low When the signal selected by parameter 33.06 Superv2 act
falls below the value of parameter 33.08 Superv2 lo, bit 1 of
06.13 Superv status is activated. To clear the bit, the signal
must exceed the value of parameter 33.07 Superv2 hi.
1
High When the signal selected by parameter 33.06 Superv2 act
exceeds the value of parameter 33.07 Superv2 hi, bit 1 of
06.13 Superv status is activated. To clear the bit, the signal
must fall below the value of parameter 33.08 Superv2 lo.
2
Abs Low When the absolute value of the signal selected by parameter
33.06 Superv2 act falls below the value of parameter 33.08
Superv2 lo, bit 1 of 06.13 Superv status is activated. To clear
the bit, the absolute value of the signal must exceed the value
of parameter 33.07 Superv2 hi.
3
Abs High When the absolute value of the signal selected by parameter
33.06 Superv2 act exceeds the value of parameter 33.07
Superv2 hi, bit 1 of 06.13 Superv status is activated. To clear
the bit, the absolute value of the signal must fall below the
value of parameter 33.08 Superv2 lo.
4
33.06 Superv2 act Selects the signal to be monitored by supervision 2. See
parameter
33.05 Superv2 func.
Speed rpm 01.01 Motor speed rpm (see page 103). 1073742081
Speed % 01.02 Motor speed % (see page 103). 1073742082
Frequency 01.03 Output frequency (see page 103). 1073742083
Current 01.04 Motor current (see page 103). 1073742084
Current % 01.05 Motor current % (see page 103). 1073742085
Tor q u e 01.06 Motor torque (see page 103). 1073742086
Dc-voltage 01.07 Dc-voltage (see page 103). 1073742087
Power inu 01.22 Power inu out (see page 103). 1073742102
Power motor 01.23 Motor power (see page 103). 1073742103
SpRef unramp 03.03 SpeedRef unramp (see page 114). 1073742595
SpRef ramped 03.05 SpeedRef ramped (see page 114). 1073742597
SpRef used 03.06 SpeedRef used (see page 114). 1073742598
Tor q R e f use d 03.14 Torq ref used (see page 115). 1073742606
Process act 04.03 Process act (see page 115
). 1073742851
Proc PID out 04.05 Process PID out (see page 115). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
No. Name/Value Description FbEq
