ABB ACS850 User Manual

218 Parameters
1 … 500% 2nd point, frequency. 1 = 1%
38.06 U/f curve freq3 Defines the frequency at the 3rd point on the custom U/f
curve in percent of parameter 99.08 Mot nom freq.
1 … 500% 3rd point, frequency. 1 = 1%
38.07 U/f curve freq4 Defines the frequency at the 4th point on the custom U/f
curve in percent of parameter 99.08 Mot nom freq.
1 … 500% 4th point, frequency. 1 = 1%
38.08 U/f curve freq5 Defines the frequency at the 5th point on the custom U/f
curve in percent of parameter 99.08 Mot nom freq.
1 … 500% 5th point, frequency. 1 = 1%
38.09 U/f curve volt1 Defines the voltage at the 1st point on the custom U/f curve in
percent of parameter 99.07 Mot nom voltage.
0 … 200% 1st point, voltage. 1 = 1%
38.10 U/f curve volt2 Defines the voltage at the 2nd point on the custom U/f curve
in percent of parameter 99.07 Mot nom voltage.
0 … 200% 2nd point, voltage. 1 = 1%
38.11 U/f curve volt3 Defines the voltage at the 3rd point on the custom U/f curve in
percent of parameter 99.07 Mot nom voltage.
0 … 200% 3rd point, voltage. 1 = 1%
38.12 U/f curve volt4 Defines the voltage at the 4th point on the custom U/f curve in
percent of parameter 99.07 Mot nom voltage.
0 … 200% 4th point, voltage. 1 = 1%
38.13 U/f curve volt5 Defines the voltage at the 5th point on the custom U/f curve in
percent of parameter 99.07 Mot nom voltage.
0 … 200% 5th point, voltage. 1 = 1%
38.16 Flux ref pointer Selects the source of the flux reference.
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
40
40 Motor control
Motor control settings.
40.01 Motor noise An optimization setting for balancing between control
performance and motor noise level.
Cyclic Control performance optimized for cyclic load applications.
Note: With this setting, the maximum motor cable length is
smaller than with Default.
0
Low noise Minimizes motor noise; control performance optimized for
high (> 300 Hz) output frequencies.
Note: Drive loadability is reduced with this setting and some
derating must be applied if a certain constant output current is
needed. This setting is not recommended for cyclic load
applications. The maximum motor cable length is 50 m
(164 ft) with drives up to 45 kW.
1
Default Control performance optimized for long motor cables. 2
No. Name/Value Description FbEq
