Parameters 155
14.72 DIO invert mask Inverts status of digital input/outputs as reported by 02.03
DIO status.
15
15 Analogue outputs
Selection and processing of actual signals to be indicated
through the analogue outputs. See section Programmable
analog outputs on page 59.
15.01 AO1 src Selects a drive signal to be connected to analogue output
AO1.
Speed rpm 01.01 Motor speed rpm (see page 103). 1073742081
Speed % 01.02 Motor speed % (see page 103). 1073742082
Frequency 01.03 Output frequency (see page 103). 1073742083
Current 01.04 Motor current (see page 103). 1073742084
Current % 01.05 Motor current % (see page 103). 1073742085
Torque 01.06 Motor torque (see page 103). 1073742086
Dc-voltage 01.07 Dc-voltage (see page 103). 1073742087
Power inu 01.22 Power inu out (see page 103). 1073742102
Power motor 01.23 Motor power (see page 103). 1073742103
SpRef unramp 03.03 SpeedRef unramp (see page 114). 1073742595
SpRef ramped 03.05 SpeedRef ramped (see page 114). 1073742597
SpRef used 03.06 SpeedRef used (see page 114). 1073742598
TorqRef used 03.14 Torq ref used (see page 115). 1073742606
Process act 04.03 Process act (see page 115). 1073742851
Proc PID out 04.05 Process PID out (see page 115). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
No. Name/Value Description FbEq
Bit Name
0 1 = Invert DIO1
1 1 = Invert DIO2
2 1 = Invert DIO3 (on optional FIO-01 I/O Extension)
3 1 = Invert DIO4 (on optional FIO-01 I/O Extension)
4 1 = Invert DIO5 (on optional FIO-01 I/O Extension)
5 1 = Invert DIO6 (on optional FIO-01 I/O Extension)
6 1 = Invert DIO7 (on optional FIO-01 I/O Extension)
7 1 = Invert DIO8 (on optional FIO-01 I/O Extension)
8 1 = Invert DIO9 (on optional FIO-01 I/O Extension)
9 1 = Invert DIO10 (on optional FIO-01 I/O Extension)
