Page #271 background image
Additional parameter data 271
Parameter groups 10…99
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
10 Start/stop/dir
10.01 Ext1 start func enum 16 0…6 - In1
10.02 Ext1 start in1 Bit pointer 32 - - DI1
10.03 Ext1 start in2 Bit pointer 32 - - C.FALSE
10.04 Ext2 start func enum 16 0…6 - Not sel
10.05 Ext2 start in1 Bit pointer 32 - - C.FALSE
10.06 Ext2 start in2 Bit pointer 32 - - C.FALSE
10.07 Jog1 start Bit pointer 32 - - C.FALSE
10.08 Jog2 start Bit pointer 32 - - C.FALSE
10.09 Jog enable Bit pointer 32 - - C.FALSE
10.10 Fault reset sel Bit pointer 32 - - DI3
10.11 Run enable Bit pointer 32 - - C.TRUE
10.13 Em stop off3 Bit pointer 32 - - C.TRUE
10.15 Em stop off1 Bit pointer 32 - - C.TRUE
10.17 Start enable Bit pointer 32 - - C.TRUE
10.19 Start inhibit enum 16 0…1 - Disabled
10.20 Start interl func enum 16 0…1 - Off2 stop
11 Start/stop mode
11.01 Start mode enum 16 0…2 - Automatic
11.02 Dc-magn time UINT32 16 0…10000 ms 500 ms
11.03 Stop mode enum 16 1…2 - Coast
11.04 Dc hold speed REAL 16 0…1000 rpm 5.0 rpm
11.05 Dc hold curr ref UINT32 16 0…100 % 30%
11.06 Dc hold enum 16 0…1 - Disabled
11.07 Autophasing mode enum 16 0…2 - Turning
12 Operating mode
12.01 Ext1/Ext2 sel Bit pointer 32 - - C.FALSE
12.03 Ext1 ctrl mode enum 16 1…5 - Speed
12.05 Ext2 ctrl mode enum 16 1…5 - Speed
12.07 Local ctrl mode enum 16 1…2 - Speed
13 Analogue inputs
13.01 AI1 filt time REAL 16 0…30 s 0.100 s
13.02 AI1 max REAL 16 -22…22 mA or -11…11 V mA or V 10.000 V
13.03 AI1 min REAL 16 -22…22 mA or -11…11 V mA or V -10.000 V
13.04 AI1 max scale REAL 32 -32768…32768 - 1500.000
13.05 AI1 min scale REAL 32 -32768…32768 - -1500.000
13.06 AI2 filt time REAL 16 0…30 s 0.100 s
13.07 AI2 max REAL 16 -22…22 mA or -11…11 V mA or V 10.000 V
13.08 AI2 min REAL 16 -22…22 mA or -11…11 V mA or V -10.000 V
