272 Additional parameter data
13.09 AI2 max scale REAL 32 -32768…32768 - 100.000
13.10 AI2 min scale REAL 32 -32768…32768 - -100.000
13.11 AI3 filt time REAL 16 0…30 s 0.100 s
13.12 AI3 max REAL 16 -22…22 mA or -11…11 V mA or V 22.000 mA
13.13 AI3 min REAL 16 -22…22 mA or -11…11 V mA or V 4.000 mA
13.14 AI3 max scale REAL 32 -32768…32768 - 1500.000
13.15 AI3 min scale REAL 32 -32768…32768 - 0.000
13.16 AI4 filt time REAL 16 0…30 s 0.100 s
13.17 AI4 max REAL 16 -22…22 mA or -11…11 V mA or V 22.000 mA
13.18 AI4 min REAL 16 -22…22 mA or -11…11 V mA or V 4.000 mA
13.19 AI4 max scale REAL 32 -32768…32768 - 1500.000
13.20 AI4 min scale REAL 32 -32768…32768 - 0.000
13.21 AI5 filt time REAL 16 0…30 s 0.100 s
13.22 AI5 max REAL 16 -22…22 mA or -11…11 V mA or V 22.000 mA
13.23 AI5 min REAL 16 -22…22 mA or -11…11 V mA or V 4.000 mA
13.24 AI5 max scale REAL 32 -32768…32768 - 1500.000
13.25 AI5 min scale REAL 32 -32768…32768 - 0.000
13.26 AI6 filt time REAL 16 0…30 s 0.100 s
13.27 AI6 max REAL 16 -22…22 mA or -11…11 V mA or V 22.000 mA
13.28 AI6 min REAL 16 -22…22 mA or -11…11 V mA or V 4.000 mA
13.29 AI6 max scale REAL 32 -32768…32768 - 1500.000
13.30 AI6 min scale REAL 32 -32768…32768 - 0.000
13.31 AI tune enum 16 0…4 - No action
13.32 AI superv func enum 16 0…3 - No
13.33 AI superv cw UINT32 32 0b0000…0b1111 - 0b0000
14 Digital I/O
14.01 DI invert mask Pb 16 0b00000000 … 0b111111111 - 0b00000000
14.02 DIO1 conf enum 16 0…2 - Output
14.03 DIO1 out src Bit pointer 32 - - Ready relay
14.04 DIO1 Ton UINT32 16 0…3000 s 0.0 s
14.05 DIO1 Toff UINT32 16 0…3000 s 0.0 s
14.06 DIO2 conf enum 16 0…3 - Output
14.07 DIO2 out src Bit pointer 32 - - RunningRelay
14.08 DIO2 Ton UINT32 16 0…3000 s 0.0 s
14.09 DIO2 Toff UINT32 16 0…3000 s 0.0 s
14.10 DIO3 conf enum 16 0…1 - Output
14.11 DIO3 out src Bit pointer 32 - - Fault(-1)
14.14 DIO4 conf enum 16 0…1 - Output
14.15 DIO4 out src Bit pointer 32 - - Ready relay
14.18 DIO5 conf enum 16 0…1 - Output
No. Name Type
Data
len.
Range Unit
Default
(Factory macro)
