ABB ACS850 - Help and Panel Version - any Mode

The ACS850 control panel 21
 Help and panel version – Any mode
How to get help
How to find out the panel version
Step Action Display
1. Press to read the context-sensitive help text for the
item that is highlighted.
If help text exists for the item, it is shown on the display.
2. If the whole text is not visible, scroll the lines with keys
and .
3. After reading the text, return to the previous display by
pressing .
Step Action Display
1. If the power is switched on, switch it off.
- If the panel cable can be disconnected easily, unplug
the panel cable from the control panel, OR
- if the panel cable can not be disconnected easily, switch
off the control board or the drive.
2. Keep key depressed while you switch on the power
and read the information. The display shows the
following panel information:
Panel SW: Panel firmware version
ROM CRC: Panel ROM check sum
Flash Rev: Flash content version
Flash content comment.
When you release the key, the panel goes to the
Output mode.
?
TIME FORMAT
DATE FORMAT
SET TIME
SET DATE
DAYLIGHT SAVING
TIME & DATE 6
EXIT
SEL
00:00
LOC
EXIT 00:00
Use Daylight saving
to enable or disable
automatic clock
adjustment according
to daylight saving
HELP
LOC
EXIT
00:00
to enable or disable
automatic clock
adjustment according
to daylight saving
changes
HELP
LOC
EXIT
TIME FORMAT
DATE FORMAT
SET TIME
SET DATE
DAYLIGHT SAVING
TIME & DATE 6
EXIT
SEL
00:00
LOC
?
?
Panel SW: x.xx
Rom CRC: xxxxxxxxxx
Flash Rev: x.xx
xxxxxxxxxxxxxxxxxxxxx
xxxxxxxxxxxxxxxxxxxxx
PANEL VERSION INFO
