Parameters 115
03.12 Torq ref sp lim Torque reference limited by the rush control (value in
percent). Torque is limited to ensure that the speed is
between the minimum and maximum speed limits defined by
parameters 20.01 Maximum speed and 20.02 Minimum
speed.
10 = 1%
03.13 Torq ref to TC Torque reference in percent for the torque control. 10 = 1%
03.14 Torq ref used Torque reference after frequency, voltage and torque limiters.
100% corresponds to the motor nominal torque.
10 = 1%
03.15 Brake torq mem Torque value (in percent) stored when the mechanical brake
close command is issued.
10 = 1%
03.16 Brake command Brake on/off command; 0 = close, 1 = open. For brake on/off
control, connect this signal to a relay output (or digital output).
See section Mechanical brake control on page 72.
1 = 1
03.17 Flux actual Actual flux reference in percent. 1 = 1%
03.18 Speed ref pot Output of the motor potentiometer function. (The motor
potentiometer is configured using parameters 21.10…21.12.)
100 = 1 rpm
03.20 Max speed ref Maximum speed reference. 100 = 1 rpm
03.21 Min speed ref Minimum speed reference. 100 = 1 rpm
04
04 Appl values
Process and counter values.
04.01 Process act1 Process feedback 1 for the process PID controller. 100 = 1 unit
04.02 Process act2 Process feedback 2 for the process PID controller. 100 = 1 unit
04.03 Process act Final process feedback after process feedback selection and
modification.
100 = 1 unit
04.04 Process PID err Process PID error, i.e. difference between PID setpoint and
feedback.
10 = 1 unit
04.05 Process PID out Output of the process PID controller. 10 = 1 unit
04.06 Process var1 Process variable 1. See parameter group 35 Process
variable.
1000 = 1
04.07 Process var2 Process variable 2. See parameter group 35 Process
variable.
1000 = 1
04.08 Process var3 Process variable 3. See parameter group 35 Process
variable.
1000 = 1
04.09 Counter ontime1 Reading of on-time counter 1. See parameter 44.01 Ontime1
func. Can be reset by entering a 0.
1 = 1 s
04.10 Counter ontime2 Reading of on-time counter 2. See parameter group 44.05
Ontime2 func. Can be reset by entering a 0.
1 = 1 s
04.11 Counter edge1 Reading of rising edge counter 1. See parameter group 44.09
Edge count1 func. Can be reset by entering a 0.
1 = 1
04.12 Counter edge2 Reading of rising edge counter 2. See parameter group 44.14
Edge count2 func. Can be reset by entering a 0.
1 = 1
04.13 Counter value1 Reading of value counter 1. See parameter group 44.19 Val
count1 func. Can be reset by entering a 0.
1 = 1
04.14 Counter value2 Reading of value counter 2. See parameter group 44.24 Val
count2 func. Can be reset by entering a 0.
1 = 1
No. Name/Value Description FbEq
