ABB ACS850 - Page 243

Parameters 243
58.16 Received packets Shows the number of message packets received by the drive,
including only such packets that are addressed to the drive.
Note: The user can reset the counter (by setting the value to
0).
0…65535 No. of message packets. 1 = 1
58.17 Transm packets Shows the number of message packets sent by the drive.
Note: The user can reset the counter (by setting the value to
0).
0…65535 No. of message packets. 1 = 1
58.18 All packets Shows the total number of message packets received by the
drive, including all packets addressed to any valid node on
the fieldbus link. Note: The user can reset the counter (by
setting the value to 0).
0…65535 No. of message packets. 1 = 1
58.19 UART errors Shows the number of messages with communication errors
other than CRC errors which the drive has received (e.g.
UART buffer overflow errors). Read only.
0..65535 No. of messages with errors (excluding messages with CRC
errors).
1 = 1
58.20 CRC errors Shows the number of messages with Cyclic Redundancy
Check (CRC) errors which the drive has received. Read only.
Note: High electromagnetic noise levels may generate errors.
0…65535 No. of messages with CRC errors. 1 = 1
58.21 Raw CW LSW Shows the LSW part of the Control Word which the drive
receives from the Modbus master. Read only.
0x0000…0xFFFF Bits 0…15 of the Control word as a hex value. 1 = 1
58.22 Raw CW MSW Shows the MSW part of the Control Word which the drive
receives from the Modbus master. Read only.
0x0000…0xFFFF Bits 16…32 of the Control word as a hex value. 1 = 1
58.23 Raw SW LSW Shows the LSW part of the Status Word which the drive
sends to the Modbus master. Read only.
0x0000…0xFFFF Bits 0…15 of the Status word as a hex value. 1 = 1
58.24 Raw SW MSW Shows the MSW part of the Status Word which the drive
sends to the Modbus master. Read only.
0x0000…0xFFFF Bits 16…32 of the Status word as a hex value. 1 = 1
58.25 Raw Ref 1 LSW Shows the LSW part of reference 1 which the drive receives
from the Modbus master. Read only.
0x0000…0xFFFF Bits 0…15 of reference 1 as a hex value. 1 = 1
58.26 Raw Ref 1 MSW Shows the MSW part of reference 1 which the drive receives
from the Modbus master. Read only.
0x0000…0xFFFF Bits 16…32 of reference 1 as a hex value. 1 = 1
58.27 Raw Ref 2 LSW Shows the LSW part of reference 2 which the drive receives
from the Modbus master. Read only.
0x0000…0xFFFF Bits 0…15 of reference 2 as a hex value. 1 = 1
58.28 Raw Ref 2 MSW Shows the MSW part of reference 2 which the drive receives
from the Modbus master. Read only.
0x0000…0xFFFF Bits 16…32 of reference 2 as a hex value. 1 = 1
No. Name/Value Description FbEq
