Parameters 171
FBA ref1 02.26 FBA main ref1 (see page 109). 1073742362
FBA ref2 02.27 FBA main ref2 (see page 109). 1073742363
D2D ref1 02.32 D2D ref1 (see page 110). 1073742368
D2D ref2 02.33 D2D ref2 (see page 110). 1073742369
Panel 02.34 Panel ref (see page 110). 1073742370
EFB ref1 02.38 EFB main ref1 (see page 114). 1073742374
EFB ref2 02.39 EFB main ref2 (see page 114). 1073742375
Mot pot 03.18 Speed ref pot (see page 115). 1073742610
PID out 04.05 Process PID out (see page 115). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
21.02 Speed ref2 sel Selects the source for speed reference 2.
Zero Zero speed reference. 0
AI1 scaled 02.05 AI1 scaled (see page 105). 1073742341
AI2 scaled 02.07 AI2 scaled (see page 105). 1073742343
Freq in 02.20 Freq in (see page 105). 1073742356
FBA ref1 02.26 FBA main ref1 (see page 109). 1073742362
FBA ref2 02.27
FBA main ref2 (see page 109). 1073742363
D2D ref1 02.32 D2D ref1 (see page 110). 1073742368
D2D ref2 02.33 D2D ref2 (see page 110). 1073742369
Panel 02.34 Panel ref (see page 110). 1073742370
EFB ref1 02.38 EFB main ref1 (see page 114). 1073742374
EFB ref2 02.39 EFB main ref2 (see page 114). 1073742375
Mot pot 03.18 Speed ref pot (see page 115). 1073742610
PID out 04.05 Process PID out (see page 115). 1073742853
Pointer Value pointer setting (see Terms and abbreviations on page
102).
-
21.03 Speed ref1 func Selects a mathematical function between the reference
sources selected by parameters 21.01 Speed ref1 sel and
21.02 Speed ref2 sel to be used as speed reference 1.
Ref1 Signal selected by 21.01 Speed ref1 sel is used as speed
reference 1 as such.
0
Add The sum of the reference sources is used as speed reference
1.
1
Sub The subtraction ([21.01 Speed ref1 sel] - [21.02 Speed ref2
sel]) of the reference sources is used as speed reference 1.
2
Mul The multiplication of the reference sources is used as speed
reference 1.
3
Min The smaller of the reference sources is used as speed
reference 1.
4
Max The greater of the reference sources is used as speed
reference 1.
5
No. Name/Value Description FbEq
