ABB ACS880-104

208 Parameters
14.14 DIO2 function (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Selects whether DIO2 of the extension module is used as a
digital input or output.
Input
Output DIO2 is used as a digital output. 0
Input DIO2 is used as a digital input. 1
14.16 DIO2 output source (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Selects a drive signal to be connected to digital input/output
DIO2 when parameter 14.14 DIO2 function is set to Output.
For the available selections, see parameter 14.11 DIO1
output source.
Not
energized
14.17 DI2 ON delay (Visible when 14.01 Module 1 type = FDIO-01)
Defines the activation delay for digital input DI2. See
parameter 14.12 DI1 ON delay.
0.00 s
0.00 … 3000.00 s Activation delay for DI2. 10 = 1 s
14.17 DIO2 ON delay (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Defines the activation delay for digital input/output DIO2. See
parameter 14.12 DIO1 ON delay.
0.00 s
0.00 … 3000.00 s Activation delay for DIO2. 10 = 1 s
14.18 DI2 OFF delay (Visible when 14.01 Module 1 type = FDIO-01)
Defines the deactivation delay for digital input DI2. See
parameter 14.12 DI1 ON delay.
0.00 s
0.00 … 3000.00 s Deactivation delay for DI2. 10 = 1 s
14.18 DIO2 OFF delay (Visible when 14.01 Module 1 type = FIO-01 or FIO-11)
Defines the deactivation delay for digital input/output DIO2.
See parameter 14.12 DIO1 ON delay.
0.00 s
0.00 … 3000.00 s Deactivation delay for DIO2. 10 = 1 s
14.19 DIO3 function (Visible when 14.01 Module 1 type = FIO-01)
Selects whether DIO3 of the extension module is used as a
digital input or output.
Input
Output DIO3 is used as a digital output. 0
Input DIO3 is used as a digital input. 1
14.19 AI supervision
function
(Visible when 14.01 Module 1 type = FIO-11 or FAIO-01)
Selects how the drive reacts when an analog input signal
moves out of the minimum and/or maximum limits specified
for the input.
The inputs and the limits to be observed are selected by
parameter 14.20 AI supervision selection.
No action
No action No action taken. 0
Fault Drive trips on 80A0 AI supervision.1
Warning Drive generates an A8A0 AI supervision warning. 2
Last speed Drive generates a warning (A8A0 AI supervision) and freezes
the speed (or frequency) to the level the drive was operating
at. The speed/frequency is determined on the basis of actual
speed using 850 ms low-pass filtering.
WARNING! Make sure that it is safe to continue
operation in case of a communication break.
3
No. Name/Value Description Def/FbEq16
