Table 4-1. Standard Displays
Display
Number
Title Point
Display*
Group
Display
1Alarm Summary
●
2 System Status
●
3 Single Loop CON0
●
4 Single Loop CON1
●
5 Single Loop CON2
●
6 Single Loop CON3
●
7 Two Loop CON0 and CON1
●
8 Two Loop CON2 and CON3
●
9 Single Loop CON0 with Horizontal Trend
●
10 Single Loop CON1 with Horizontal Trend
●
11 Single Loop CON2 with Horizontal Trend
●
12 Single Loop CON3 with Horizontal Trend
●
13 Parameter Module 0
●
14 Parameter Module 1
●
15 Parameter Module 2
●
16 Parameter Module 3
●
17 Parameter Module 4
●
18 Parameter Module 5
●
19 Parameter Module 6
●
20 Parameter Module 7
●
21 Status Module 0
●
22 Status Module 1
●
23 Totalizer Module 0
●
24 Totalizer Module 1
●
25 Totalizer Module 2
●
26 Totalizer Module 3
●
27 Totalizer Module 4
●
28 Totalizer Module 5
●
29 Totalizer Module 6
●
30 Totalizer Module 7
●
31 Locator Grid
32 Four Loop CON0 - CON3
●
*Point Displays can be any of six types (0-5): 0 - Standard PID, 1 - Indicator, 2 - Manual Loader,
3 - Ratio Controller, 4 - Auto/Manual (A/M) Station, and 5 - Ratio A/M Station.
