5.16 CONFIGURATION SUMMARY
Figure 5-2 illustrates the general approach to customizing and configuring the controller.
Figure 5-2. Configuration Summary
INSTALL CONTROLLER PER
SECTION 2, INSTALLATION.
STANDARD FACTORY CON-
FIGURATION AS DESCRIBED
IN SECTION 6 FOR CS1, 11
FOR CS20, OR 15 FOR CS41?
YES NO
TUNE PER SECTION 16,
TUNNING PID PARAMETERS
OR SECTION 17, EASY-TUNE.
IN
SERVICE
CHOOSE A CONTROL STRATEGY AS DESCRIBED IN SECTIONS 6 - 15.
DESIGN A NEW CONTROL
STRATEGY WIRELIST USING
FCS (SEE FCS GUIDE).
DESIGN A NEW CONTROL
STRATEGY USING F-CIM
(SEE CUSTOMIZATION GUIDE).
MODIFY A CONTROL
STRATEGY FROM SECTIONS
6 - 15 WITH FCS (SEE FCS
GUIDE).
DESIGN A NEW CONTROL
STRATEGY USING F-TRAN
(SEE CUSTOMIZATION
GUIDE).
CONFIGURE TABLE 5-14, COMMUNICATION MODULE (SO THAT
REMAINING CONFIGURATION CAN BE DONE AT PERSONAL COMPU-
TER USING ONE OF THE SOFTWARE APPLICATION PACKAGES
LISTED IN THE TABLE OF SECTION 3.2). CONFIGURE TABLE 5-4,
ANALOG INPUT MODULES; TABLE 5-5, ANALOG OUTPUT MODULES;
TABLE 5-9, CONTROLLER MODULES; TABLE 5-6, CONTACT CLOSURE
INPUT MODULES; AND TABLE 5-7, CONTACT CLOSURE OUTPUT
MODULES.
ADD DISPLAYS BY CHANGING THE DISPLAY LIST IN TABLE 5-15,
SYSTEM AND MISCELLANEOUS MODULE. CONFIGURE TABLE 5-10,
STATUS DISPLAY MODULES; TABLE 5-11, PARAMETER MODULES;
AND TABLE 5-13,
