6.5 CS1 SOFT-WIRE LIST MODIFICATIONS
Table 6-4 lists values that can be entered into designated soft-wire list datapoints to alter CS1 func-
tionality.
Table 6-4. CS1 Soft-Wire List Modifications
To force control to manual on a momentary contact closure of DI0:
Set B133 = 97
To set controller output to a fixed value while DI0 is an open contact:
Set B160 = 129 and Set C129 to desired value.
To force the output to track AI3 while DI0 is a closed contact and to set the controller to manual
when the tracking operation is ended by opening the DI0 contact:
Set B133 = 0, Set B129 = 128, and Set B159 = 97.
DO0 indicates either Process Alarm 1 or Process Alarm 2 active, and DO1 indicates the Totalizer
0 rollover pulse:
Set B172 = 1 and Set B106 = 224.
DO0 indicates remote and auto while DO1 indicates Process Alarm 1:
Set B170 = 107, Set B171 = 108, Set B172 = 2, and Set B106 = 110.
Multiplying Feed Forward (FF)
(
OUT
=
OUT
×
FF
SCALE
×
MULTIPLIER
)
:
Disable Feed Forward by setting B155 = 122, and C122 = 0.0,
Disable Output Tracking by setting L119 = 0,
Set B165 = 6,
Set C79 - Multiplier for desired output response, and
Set C81 - Scaler to make FF Signal 0 - 1



FF
C81



.
For control PV compensated gas flow (linear) with AI2 - pressure and AI3 - temperature:
Disable Feed Forward by setting B155 = 122 and C122 = 0.0,
Disable Output Tracking by setting L119 = 0,
Set B122 = 18, and
Set C354, C356 - C359 as required (see IB 53MC5000 Flexible Control Strategies
for compensated gas flow information).
For control PV compensated gas flow (square root) with AI2 - pressure and AI3 - temperature:
Disable Feed Forward by setting B155 = 122 and C122 = 0.0,
Disable Output Tracking by setting L119 = 0,
Set B122 = 19, and
Set C354 - C359 as required (see IB 53MC5000 Flexible Control Strategies
for compensated gas flow information).
To make an Integral (I) only controller:
Set B155 = 122, Set B163 = 30, Set B165 = 2, Set C122 = 0.0,
Set C79 = 1.0, Set C80 = 1.0, and Set C106 = 100.0.
