ABB ControlIT 53MC5000 User Manual

Table 18-2. Controller Parts List
Item Part Number Description
14
177A128U12 0 to +120
°
C (10 ohms @ 25
°
C) (Analog Devices Inc. 5B34-C-02)
177A128U13 120 ohms ni, 0 to +300
°
C (Analog Devices Inc. 5B34-N-01)
177A128U14 Type J, 0 to +760
°
C (Analog Devices Inc. 5B47-J-01)
177A128U15 Type J, -100
°
C to +300
°
C (Analog Devices Inc. 5B47-J-02)
177A128U16 Type J, 0 to +500
°
C (Analog Devices Inc. 5B47-J-03)
177A128U17 Type K, 0 to +1000
°
C (Analog Devices Inc. 5B47-K-04)
177A128U18 Type K, 0 to + 500
°
C (Analog Devices Inc. 5B47-K-05)
177A128U19 Type T, -100
°
to +400
°
C (Analog Devices Inc. 5B47-T-06)
177A128U20 Type T, 0 to +200
°
C (Analog Devices Inc. 5B47-T-07)
177A128U21 Type E, 0 to +1000
°
C (Analog Devices Inc. 5B47-E-08)
177A128U22 Type R, +500
°
to +1750
°
C (Analog Devices Inc. 5B47-R-09)
177A128U23 Type S, +500
°
to +1750
°
C (Analog Devices Inc. 5B47-S-10)
177A128U24 Type B, +500
°
to +1800
°
C (Analog Devices Inc. 5B47-B-11)
177A128U25 0 to 20 mA (Also requires AC 1362 installed in R17) (Analog
Devices Inc. 5B32-02)
15
686B625U01 16DI/DO PCB, Option
686B625U02 16DI/DO PCB, Option, Conformal Coating
161M417U05 Precision AI resistor, 0.1%, 250 ohm
Table 18-3. Related Parts List
Part Number Description
686B613U01 6DI/4DO ITB - 8.25 in. (210 mm) long
686B613U03 6DI/4DO ITB - 8.25 in. (210 mm) long, Conformal Coating
686B614U01 Dual Relay ITB - 3.5 in. (89 mm) long
686B614U03 Dual Relay ITB - 3.5 in. (89 mm) long, Conformal Coating
686B616U01 Cord Set ITB - 4.5 in. (108 mm) long
686B616U03 Cord Set ITB - 4.5 in. (108 mm) long, Conformal Coating
686B617U01 Analog ITB - 6 in. (153 mm) long
686B628U01 16DI/DO ITB
686B628U02 16DI/DO ITB, Conformal Coating
686B622U01 Communications ITB (COMM)
686B622U02 Communications ITB (COMM), Conformal Coating
686B599U01 Communications PCB
686B599U02 Communications PCB, Conformal Coating
686B615U01 SCADA Adapter
677B944U01 ITB Cable Assembly - 5 feet (1.52 m)
677B944U02 ITB Cable Assembly - 10 feet (3.05 m)
677B944U03 ITB Cable Assembly - 25 feet (7.62 m)
173D109U03 U.S. Power Cord - 120 V ac, 50/60 Hz
355J093U01 Trim Collar for Single Case
614B836U01 Trim Collar and Spacers for Two Cases
3 of 3
1 of 2
Section 18. Maintenance and Parts List
18-9
