Figure 4-3. Point Displays 3, 4, 5, and 6 (CDM = 0, Standard PID)
(Sheet 2 of 5)
HORN OVERLAY (A009 =
’wALARMx’, L065 = 1, AND
L063 = 0)
HIGH ALARM OVERLAY
PROCESS VARIABLE BAR
PASSED HIGH ALARM LIMIT
ALARM LIMIT 1 (C103)
HORN OVERLAY (A009 =
’wALARMx’, L065 = 1, AND
L063 = 0)
LOW ALARM OVERLAY
ALARM LIMIT 2 (C104)
PROCESS VARIABLE BAR
BELOW LOW ALARM LIMIT
CON0 HIGH AND LOW ALARM
OVERLAYS
53MC5000 Process Control Station
4-12
