Table 5-4. Analog Input Modules (AI0-8)
Title Definition Atom AI0 AI1 AI2 AI3 AI4 AI5 AI6 AI7 AI8 Default
Square Root
Signal
This value specifies the
characteristics of the signaling input
as either linear or square root.
0
- Linear
1
- Square Root
When square root is selected, input
signals less than 1% after
linearization (10% input range)
force the input to its zero value.
SQRT
(0-8)
L440 L441 L442 L443 L444 L445 L446 L447 L448 0
Calibrate
Zero
This is the calibration zero
adjustment. This parameter
is
factory set
and
should not need
adjustment
under normal
operation. See Section 18.4 for
additional information.
CIZ
(0-8)
B263 B264 B265 B266
Calibrate
Span
This is the calibration span
adjustment. This parameter
is
factory set
and
should not need
adjustment
under normal
operation. See Section 18.4 for
additional information.
CIS
(0-8)
C296 C297 C298 C299
Frequency
Input
This specifies whether the signaling
input is a voltage or frequency.
0
- Voltage
1
- Frequency
The value of the input becomes
(Span X Freq) + Zero
See Section 1, Specifications, for
duty cycle input requirements.
FREQ
(0-8)
L468 L469 L470 L471 0
2 of 3
5-6
53MC5000 Process Control Station
