Table 5-13. Totalizer Modules
Parameter Definition Symbol01234567Default
Actual
Total
This parameter indicates the integer value of the total
accumulation.
TO
(0-7)
H032 H033 H034 H035 H036 H037 H038 H039 0
Output
Pulse
This value is pulsed to a
1
for one scan each time the
actual total reaches the rollover value.
TMP
(0-7)
L224 L225 L226 L227 L228 L229 L230 L231 0
Display
This is the index number for the display that provides
access through the totalizer module.
23 24 25 26 27 28 29 30
2 of 2
5-31
