Table 5-14. System Module
Title Definition Atom Data-
point
De-
fault
Display
Program
This value is the current display program index number. DSPL B005 3
Display
Brightness
This parameter controls the display screen intensity. For Model 53MC5000
A
controllers and
Model 53MC5000
B
controllers
with the Low-Res display
, index values from 0 to 7 determine
brightest (0) to dimmest (7) intensity. This parameter has negligible effect on display brightness
in 53MC5000
B
controller models with the Hi-Res display.
BRGT B012 4
Alarm
Disable
Alarm line annunciation can be inhibited. Normally when datapoint L065 is a 1, the contents of
datapoint A009 are superimposed over the current display. If datapoint L063 is set to a 1, no
superimposing will occur.
NALIN L063 0
Alarm
Line
The value placed in this parameter will be presented at the top of the display whenever an
unacknowledged alarm condition exists.
ALINE A009 ALARM
Display
List
These datapoints contain the index numbers of the displays to be presented in the desired
sequence. The display list is organized such that each group of displays is made of consecutive
datapoints with one group immediately following the preceding group. The display list allows
entries for up to 8 groups with 8 displays each. Index numbers correspond to any user written
display program (see Customization Guide 53MC5000) or to the list of preprogrammed standard
displays that is provided in Section 4.
A display list example of preprogrammed standard displays for a two loop controller (CON0 and
CON1) with a locator grid that has three display groups (three columns) and three displays per
group (three rows) would be as follows:
B21 = 1 Alarm Summary (Column 1, Row 1)
B22 = 7 Two Loop CON0 and CON1 (Column 1, Row 2)
B23 = 21 Status Module 0 (Column 1, Row 3)
B24 = 14 Parameter Module 1 (Column 2, Row 1)
B25 = 9 Single Loop CON0 with Horizontal Trend (Column 2, Row 2)
B26 = 13 Parameter Module 0 (Column 2, Row 3)
B27 = 18 Parameter Module 5 (Column 3, Row 1)
B28 = 10 Single Loop CON1 with Horizontal Trend (Column 3, Row 2)
B29 = 17 Parameter Module 4 (Column 3, Row 3)
B021-
B084
5 of 6
5-36
53MC5000 Process Control Station
