ABB ControlIT 53MC5000 User Manual

Table 9-3. CS4 Automatic/Manual Station Datapoints
Data-
point Table Module Title and Function
De-
fault
Alarms Related Datapoints
B335 5-9 CON0 Control Alarm Mode - Used to select one of six alarm types
or none. See Table 5-9 for details and examples.
1
C103 5-9 CON0 Alarm Limit 1 - Point in engineering units where an alarm is
triggered because the Alarmed Variable is not within the limit
value set in C103.
100
C104 5-9 CON0 Alarm Limit 2 - Point in engineering units where an alarm is
triggered because the Alarmed Variable is not within the limit
value set in C104.
0
C105 5-9 CON0 Alarm Dead Band - Sets the activation/deactivation gaps for
the alarm limit points. It is in engineering units.
2
Miscellaneous Datapoints
A000 5-9 CON0 Tagname - Assignable 10 character name. CON-
0
A001 5-9 CON0 Engineering Units - Assignable 10 character designator. PER-
CENT
3 of 3
Section 9. CS4 - Automatic/Manual Station
9-7
