Table 10-3. CS5 Ratio Automatic/Manual Station Datapoints
Data-
point Table Module Title and Function
De-
fault
DI0 - Force Output Tracking
L264 5-6 DI0 Contact Input Invert - Normally, Force Output Tracking is
enabled if DI0 is open (and datapoint L119 - Enable Output
Tracking = 1). Set to 1 to reverse the DI0 condition required
to activated output tracking (DI0 closed = Force Output
Tracking).
0
DI1 - Select Remote Ratio
L265 5-6 DI1 Contact Input Invert - Normally, Select Remote Ratio is
permitted if DI1 is closed. Set to 1 to reverse the DI1
condition required to permit Select Remote Ratio (DI1 open =
Select Remote Ratio).
0
DO0 - Process Alarm 1
L288 5-7 DO0 Contact Output Invert - Normally, Process Alarm 1 is enabled
if DO0 is closed. Set to 1 to reverse the DO0 condition
required to activate Process Alarm 1 (DO0 open = the
Alarmed Variable value is not within the C103 limit).
0
DO1 - Process Alarm 2
L289 5-7 DO1 Output Invert - Normally, Process Alarm 2 is enabled if DO1
is closed. Set to 1 to reverse the DO1 condition required to
activate Process Alarm 2 (DO1 open = the Alarmed Variable
value is not within the C104 limit).
0
Alarms Related Datapoints
B335 5-9 CON0 Control Alarm Mode - Used to select one of six alarm types
or none. See Table 5-9 for details and examples.
1
C103 5-9 CON0 Alarm Limit 1 - Point in engineering units where an alarm is
triggered because the Alarmed Variable is not within the limit
value set in C103.
100
C104 5-9 CON0 Alarm Limit 2 - Point in engineering units where an alarm is
triggered because the Alarmed Variable is not within the limit
value set in C104.
0
C105 5-9 CON0 Alarm Dead Band - Sets the activation/deactivation gaps for
the alarm limit points. It is in engineering units.
2
Miscellaneous Datapoints
A000 5-9 CON0 Tagname - Assignable 10 character name. CON-
0
A001 5-9 CON0 Engineering Units - Assignable 10 character designator. PER-
CENT
3 of 3
Section 10. CS5 - Ratio Automatic/Manual Station
10-7
