ABB ControlIT 53MC5000 User Manual

Table 15-3. CS41 Four Loop Controller Datapoints
Data-
point Table Module Title and Function
De-
fault
Setpoint Related Datapoints (Loops 1, 2, 3, 4) (Cont)
C117,
C153,
C189,
C225
5-9 CON0,
CON1,
CON2,
CON3
Setpoint Slew Rate - It is a rate limit applied to the setpoint.
When configured to a non-zero value, the setpoint used in
the PID algorithm is only allowed to change by this amount
each scan time. The final value of the setpoint always
appears on the units display. A zero disables setpoint
slewing.
0
Miscellaneous Datapoints (Loops 1, 2, 3, 4)
A008 Unit Tagname - Assignable 10 character name, e.g.,
ABB MC5000.
A000,
A002,
A004,
A006
5-9 CON0,
CON1,
CON2,
CON3
Tagname - Assignable 10 character name. CON-
0, 1,
2, 3
A001,
A003,
A005,
A007
5-9 CON0,
CON1,
CON2,
CON3
Engineering Units - Assignable 10 character designator.
(Engineering Units appear on the Trend displays.)
PER-
CENT
13 of 13
Section 15. CS41 - Four Loop Controller
15-21
