Table 1-5. OPTO 22 Module Specifications for 16DI/DO ITB
OPTO 22 DC Input Modules (Cont)
OPTO 22
Part Number
16DI/DO
Voltage Input Voltage Range
Input
Current @
Max V In
Input
Maximum
for No Output
G41DC5G 5 V dc 35 - 60 V dc 6 mA 9 V dc
G41AC5 5 V dc 90 - 140 V dc 11 mA 45 V dc
G41AC5A 5 V dc 180 - 280 V dc 6.5 mA 80 V dc
G41DC24 24 V dc 10 - 32 V dc 25 mA 3 V dc
G41AC24 24 V dc 90 - 140 V dc 11 mA 45 V dc
OPTO 22 DC Output Modules
OPTO 22
Part Number
16DI/DO
Voltage
Output Line
Voltage
Range
Load
Current
@ 45
°
C
Load
Current
@ 70
°
C
Maximum
Off State
Leakage
G40DC5 5 V dc 5 - 60 V dc 3 Amps 2 Amps 1 mA
G40DC5A 5 V dc 5 - 200 V dc 1 Amp 0.55 Amp 2 mA
G40DC24 24 V dc 5 - 60 V dc 3 Amps 2 Amps 1 mA
Table 1-6. Single Channel Analog Input Option (AI8) Specifications
Item Specification(s)
This option requires one of the 5B series isolation modules described in Table 1-8.
Safety classification FM Approved: Nonincendive for Class 1, Div. 2, Group A,
B, C, & D hazardous locations.
Quantity 1 (Analog Input 8 - AI8).
Analog-to-digital specifications:
Accuracy
Resolution
±
0.1% Full Scale
12 bits
2 of 2
Section 1. Introduction
1-17
