Table 18-4. Isolated Discrete I/O Modules for the
16DI/DO ITB
OPTO 22 Part Number ITB Voltage Max. Input Current Input Voltage Range
OPTO 22 AC Input Modules
G4IDC5 5 V dc 25 mA 12-32 V ac
G4IDC5G 5 V dc 25 mA 35-60 V ac
G4IAC5 5 V dc 11 mA 90-140 V ac
G4IAC5A 5 V dc 6.5 mA 180-280 V ac
G4IDC24 24 V dc 25 mA 10-32 V ac
G4IAC24 24 V dc 11 mA 90-140 V ac
OPTO 22 AC Output Modules
G4OAC5 5 V dc 3 A 12-140 V ac
G4OAC5A 5 V dc 3 A 24-280 V ac
G4OAC5A5 (NC) 5 V dc 3 A 24-280 V ac
G4OAC24 24 V dc 3 A 12-140 V ac
G4OAC24A 24 V dc 3 A 24-280 V ac
OPTO 22 DC Input Modules
G4IDC5 5 V dc 25 mA 10-32 V dc
G4IDC5B 5 V dc 45 mA 4-16 V dc
G4IDC5D 5 V dc 30 mA 2.5-28 V dc
G4IDC5G 5 V dc 6 mA 35-60 V dc
G4IAC5 5 V dc 11 mA 90-140 V dc
G4IAC5A 5 V dc 6.5 mA 180-280 V dc
G4IDC24 24 V dc 25 mA 10-32 V dc
G4IAC24 24 V dc 11 mA 90-140 V dc
OPTO 22 DC Output Modules
G4ODC5 5 V dc 3 A 5-60 V dc
G4ODC5A 5 V dc 1 A 5-200 V dc
G4ODC24 24 V dc 3 A 5-60 V dc
18.4 CALIBRATION
The controller’s
analog inputs (AI0-3) and analog outputs (AO0&1)
normally do not require
recalibration. If it becomes necessary to recalibrate the controller due to the inadvertent change of
the stored calibration values, then this can be accomplished by altering their respective datapoints.
The calibration zero and span datapoint locations are as follows:
AI0 AI1 AI2 AI3 AO0 AO1
Calibrate Zero B263 B264 B265 B266 B267 B268
Calibrate Span C296 C297 C298 C299 C300 C301
Note: The spans have a nominal value of 1.0 and can be adjusted
up or down within the range of 0.8 to 1.2. The zeros have a nom-
inal value of 128 and can be adjusted up or down within the range
of 100 to 150.
Section 18. Maintenance and Parts List
18-11
