Table D-13. System Module
Page * Name Atom Datapoint Default
Execute
Unit Tag Name TAG A008 MC5000
Function Index FIX B000 0
Scan Index SCAN B003 1
Background Program BACK B008 0
Background Scan Index BSCAN B006 1
Link List Load LLD B016 0
Forced Output FXM B333 0
Power Up PWRUP L066 0
Counter
Counter Mode CMODE L075 0
Seconds SEC B257 0
Minutes MIN B258 0
Hours HOURS B259 0
Month DAY B260 0
Day MONTH B261 0
Year YEAR B262 0
Comm.
Instrument Address * IA B001 0
Baud Rate * BR B002 253
No Parity * CP L256 0
No Byte Stuffing * CB L258 0
Datalink Disable * DLD L257 0
Display
Display Program DSPL B005 3
Display Brightness Index BRIGHT B012 4
Number of [Display] Groups MDG B017 1
Number of Displays per Group MDS B018 5
No Alarm Line Annunciation NALIN L063 0
Alarm Line Output ALINE A009 ALARM
EZ-Tune
Control Module Selector * LPS B385 0
PID Control Mode * CM B386 0
Lowest TR Minutes * TLIM C387 0
Max. Allowed PV Deviation * DPV C380 0
Output Step Change Value 0 * DOUT C381 0
Initial PV Response Limit * DPPV C378 2
Enable Tuning Parameter Limits * PLIM L520 1
Automatic Tuning Parameter Entry * APLD L522 0
Appendix D. Database
D-9
