Table D-14. Database - L Type Datapoints
Data-
point
Name Module Atom Default Table
L074 User Log Enable ULE
L075 Counter Mode
System
CMODE 0
5-14
L076 HiRes Disable HD 0
L077 Display FTran Control DFC 0
L078 SDT0 Process Alarm
SDT
SPA0 0
L079 SDT1 Process Alarm SPA1 0
L080-
L103
FCS 0
L104 SP Track Status
Controller 0
SPTS0 0
5-9
L105 Output Track Status OVTS0 0
L106 Reverse Switch RSW0 1
L107 Auto Status AUT0 0
L108 Remote Status RMT0 0
L109 Reverse Valve RSV0 0
L110 Alarm A Active PA10 0
L111 Alarm B Active PA20 0
L112 Auto Switch SWA0 0
L113 Remote Switch SWR0 0
L114 Auto Enable AE0 1
L115 Remote Setpoint Enable RE0 0
L116 Setpoint Track Switch SWSPT0 0
L117 Output Track Switch SWOVT0 0
L118 Setpoint Track Enable STE0 0
L119 Output Track Enable OTE0 0
L120 Manual Fallback Disable MFD0 0
L121 Reserved 0
L122 Hard Manual Limit
Controller 0
HML0 1
5-9
L123 Control Track Command CTC0 0
L124 Reserved 0
L125 Alarm Acknowledge
Controller 0
AK0 0
5-9
L126 Alarm AA Past State LA0 0
L127 Alarm AB Past State LB0 0
L128 SP Track Status
Controller 1
SPTS1 0
L129 Output Track Status OVTS1 0
L130 Reverse Switch RSW1 1
L131 Auto Status AUT1 0
L132 Remote Status RMT1 0
L133 Reverse Valve RSV1 0
L134 Alarm A Active PA11 0
L135 Alarm B Active PA21 0
L136 Auto Switch SWA1 0
L137 Remote Switch SWR1 0
