ABB ControlIT 53MC5000 - Page 365

Table D-14. Database - L Type Datapoints
Data-
point
Name Module Atom Default Table
L180 Remote Status
Controller 3
RMT3 0
5-9
L181 Reverse Valve RSV3 0
L182 Alarm A Active PA13 0
L183 Alarm B Active PA23 0
L184 Auto Switch SWA3 0
L185 Remote Switch SWR3 0
L186 Auto Enable AE3 1
L187 Remote Setpoint Enable RE3 0
L188 Setpoint Track Switch SWSPT3 0
L189 Output Track Switch SWOVT3 0
L190 Setpoint Track Enable STE3 0
L191 Output Track Enable OTE3 0
L192 Manual Fallback Disable MFD3 0
L193 Reserved 0
L194 Hard Manual Limit HML3 1
5-9
L195 Control Track Command CTC3 0
L196 Reserved 0
L197 Alarm Acknowledge AK3 0
5-9
L198 Alarm AA Past State LA3 0
L199 Alarm AB Past State LB3 0
L200-
L223
Peer-to-Peer Communication Status
(0 = Invalid, 1 = Valid)
External
PSTAT0-
PSTAT23
05-8
L224-
L231
Totalizer 0-7 Output Pulse Totalizer
TMP0-
TMP7
05-13
L232-
L239
Totalizer 0-7 Reset Totalizer
TMR0-
TMR7
05-13
L240-
L247
Reserved Temporaries
BLTEMP
1 - 8
0
L248-
L255
Reserved Temporaries
FLTEMP
1 - 8
0
L256 Datalink No Parity
COMM
CP 0
5-14
L257 Datalink Disable DLD 0
L258 Datalink No Byte Stuffing CB 0
L259 Gateway On GATE 0
L260 Gateway Interrogator/Responder
Mode (0 = Responder, 1 =
Interrogator)
GDR 0
L261 Reserved 0
L262 MicroLink Retry Disable 0
L263 Auto Connect Disable 0
L264 DI0 Discrete Input Invert (Standard)
DI
IINV0 0
5-6
L265 DI1 Discrete Input Invert (Standard) IINV1 0
4 of 6
53MC5000 Process Control Station
D-14
