ABB ControlIT 53MC5000 - Page 367

Table D-14. Database - L Type Datapoints
Data-
point
Name Module Atom Default Table
L436-
L439
Reserved 0
L440-
L443
AI0 through AI3 Square Root Signal
(Standard)
AI
SQRT0-
SQRT3
0
5-4
L444-
L448
AI4 through AI8 Square Root Signal
(Optional)
SQRT4-
SQRT8
0
L449-
L459
AI
n
Square Root Signal (Optional) SQRT
n
0
L460-
L467
Reserved 0
L468-
L471
AI4 through AI7 Frequency Input
(Optional)
AI
FREQ4-
FREQ7
05-4
L472-
L473
AO0 and AO1 0-20 mA Output
(Standard)
AO
BASE0-
BASE1
0
5-5
L474-
L475
AO0 and AO1 0-20 mA Output
(Optional)
BASE2-
BASE3
0
L476-
L489
AI
n
0-20 mA Output (Optional) BASE
n
0
L490-
L503
Reserved 0
L504-
L511
Reserved Temporaries
BLTEMP
9 - 16
0
L512-
L519
Reserved Temporaries
FLTEMP
9 - 16
0
L520 Enable Tuning Parameter Limits
EASY-
TUNE
PLIM 1
17-2
L521 Abort EASY-TUNE Switch 0
L522 Automatic Tuning Parameter Entry APLD 0
L523-
L534
EASY-TUNE Reserved 0
L535-
L799
Reserved 0
L800-
L999
Unassigned 0
6 of 6
