Table D-16. Database - C Type Datapoints
Data-
point
Name Module Atom Default Table
C000 Analog Output 0
AO
AO0 0
5-5
C001 Analog Output 1 AO1 0
C002 Analog Output 2 (Optional) AO2 0
C003 Analog Output 3 (Optional) AO3 0
C004-
C017
Analog Outputs (Optional) AO
n
0
C018
C019
Reserved 0
C020-
C036
FCS 0
C037-
C046
FCS 0/1
C047-
C063
Reserved 0
C064 AI7 Scan Pulse Count
AI
AIPI7 0
5-4
C065 AI6 Scan Pulse Count AIPI6 0
C066 AI5 Scan Pulse Count AIPI5 0
C067-
C075
Reserved 0
C076 Math A - K1 0
C077 Math A - K2 0
C078 Math A - K3 0
C079 Math B - K1 0
C080 Math B - K2 0
C081 Math B - K3 0
C082 Math C - K1 0
C083 Math C - K2 0
C084 Math C - K3 0
C085 Math D - K1 0
C086 Math D - K2 0
C087 Math D - K3 0
C088 Math E - K1 0
C089 Math E - K2 0
C090 Math E - K3 0
C091 Math F - K1 0
C092 Math F - K2 0
C093 Math F - K3 0
C094 Math G - K1 0
C095 Math G - K2 0
C096 Math G - K3 0
C097 Math H - K1 0
C098 Math H - K2 0
C099 Math H - K3 0
1 of 7
Appendix D. Database
D-23
