Table D-17. Database - H Type Datapoints
Data-
point
Name Module Atom Default Table
H000 Analog Input 0 (Standard)
AI
AI0 0
5-4
H001 Analog Input 1 (Standard) AI1 0
H002 Analog Input 2 (Standard) AI2 0
H003 Analog Input 3 (Standard) AI3 0
H004 Analog Input 4 (Optional) AI4 0
H005 Analog Input 5 (Optional) AI5 0
H006 Analog Input 6 (Optional) AI6 0
H007 Analog Input 7 (Optional) AI7 0
H008 Analog Input 8 (Optional) AI8 0
H009-
H019
Analog Inputs 9 through 19
(Optional)
AI
n
0
H020 Reset Generator
Controller-0
RN0 0
5-9
H021 Rate Generator DN0 0
H022 Reserved 0
H023 Reset Generator
Controller-1
RN1 0
5-9
H024 Rate Generator DN1 0
H025 Reserved 0
H026 Reset Generator
Controller-2
RN2 0
5-9
H027 Rate Generator DN2 0
H028 Reserved 0
H029 Reset Generator
Controller-3
RN3 0
5-9
H030 Rate Generator DN3 0
H031 Reserved 0
H032 Totalizer 0 Actual Total
Totalizer
TO0 0
5-13
H033 Totalizer 1 Actual Total TO1 0
H034 Totalizer 2 Actual Total TO2 0
H035 Totalizer 3 Actual Total TO3 0
H036 Totalizer 4 Actual Total TO4 0
H037 Totalizer 5 Actual Total TO5 0
H038 Totalizer 6 Actual Total TO6 0
H039 Totalizer 7 Actual Total TO7 0
H040 Totalizer 0 Work Area TT0 0
H041 Totalizer 1 Work Area TT1 0
H042 Totalizer 2 Work Area TT2 0
H043 Totalizer 3 Work Area TT3 0
H044 Totalizer 4 Work Area TT4 0
H045 Totalizer 5 Work Area TT5 0
H046 Totalizer 6 Work Area TT6 0
H047 Totalizer 7 Work Area TT7 0
H048 Totalizer 0 Rollover Value
Totalizer
TMM0 0
5-13
H049 Totalizer 1 Rollover Value TMM1 0
H050 Totalizer 2 Rollover Value TMM2 0
1 of 2
53MC5000 Process Control Station
D-30
