Table D-18. Database - A Type Datapoints
Data-
point
Name Module Atom Default Table
A000 Tag Name
Controller-0
TAG CON0
5-9
A001 Engineering Units EU CON0
A002 Tag Name
Controller-1
TAG CON1
A003 Engineering Units EU CON1
A004 Tag Name
Controller-2
TAG CON2
A005 Engineering Units EU CON2
A006 Tag Name
Controller-3
TAG CON3
A007 Engineering Units EU CON3
A008 Unit Tag Name
System
TAG MC5000
5-14
A009 Alarm Line Output ALINE ALARM
A010 Parameter Module 0 Title
Parameter
TAG CON0 TUNE
5-11
A011 Point 1 Name, Module 0 PNA0 PROP BAND
A012 Point 2 Name, Module 0 PNB0 RESET
A013 Point 3 Name, Module 0 PNC0 RATE
A014 Parameter Module 1 Title TAG CON0 ALRM
A015 Point 1 Name, Module 1 PNA1 PROC LIM1
A016 Point 2 Name, Module 1 PNB1 PROC LIM2
A017 Point 3 Name, Module 1 PNC1 ALRM DBAND
A018 Parameter Module 2 Title TAG CON0 OUTV
A019 Point 1 Name, Module 2 PNA2 OUT HI LIM
A020 Point 2 Name, Module 2 PNB2 OUT LO LIM
A021 Point 3 Name, Module 2 PNC2 OUT SLEW
A022 Parameter Module 3 Title TAG CON0 SPV
A023 Point 1 Name, Module 3 PNA3 SP HI LIM
A024 Point 2 Name, Module 3 PNB3 SP LO LIM
A025 Point 3 Name, Module 3 PNC3 SP SLEW
A026 Parameter Module 4 Title TAG CONO TUNE
A027 Point 1 Name, Module 4 PNA4 PROP BAND
A028 Point 2 Name, Module 4 PNB4 RESET TIME
A029 Point 3 Name, Module 4 PNC4 DERIV TIME
A030 Parameter Module 5 Title TAG CON1 ALRM
A031 Point 1 Name, Module 5 PNA5 PROC LIM1
A032 Point 2 Name, Module 5 PNB5 PROC LIM2
A033 Point 3 Name, Module 5 PNC5 ALRM DBAND
A034 Parameter Module 6 Title TAG CON1 OUTV
A035 Point 1 Name, Module 6 PNA6 OUT HI LIM
A036 Point 2 Name, Module 6 PNB6 OUT LO LIM
A037 Point 3 Name, Module 6 PNC6 ALRM DBAND
A038 Parameter Module 7 Title TAG CON1 SPV
A039 Point 1 Name, Module 7 PNA7 SP HI LIM
A040 Point 2 Name, Module 7 PNB7 SP LO LIM
A041 Point 3 Name, Module 7 PNC7 SP SLEW
1 of 6
53MC5000 Process Control Station
D-32
