ABB IRB 1400 - Updating Revolution Counters

6 Calibration information
6.0.3 Calibration scales and correct axis position
134 3HAC021111-001 Revision: B
6.0.3 Calibration scales and correct axis position
Introduction This section specifies the calibration scale positions and/or correct axis position for all robot
models.
Calibration
scales, IRB 1400
The illustration below shows the calibration scale positions on IRB 1400:
en0200000272
