ABB IRB 1400 - Sheet 109 Integrated Wirefeed Cabling (Option)

11 Circuit diagram
11.0.10 Sheet 109 Integrated wirefeed cabling (Option)
3HAC021111-001 Revision: B 179
11.0.10 Sheet 109 Integrated wirefeed cabling (Option)
CSA CSJ CSB CSC CSD CSE CSF CSG CSH CSP CSK CSL CSM CSN CSR CSS
GY WH VT WH BU WH GN WH YE WH OG WH RD WH BN WH S
R N M L H K P
G F J E D C B A
S R N M L H K P
G F J E D C B A
M L J K F G H C E B D A
CPM CPL CPJ CPK CPF CPG CPH CPC CPE CPB CPD CPA CPD CPA
M L J K F G H C E B D A
4 5 6 7 8 9 10 11 12 13 14 15
16 17
R2.CS
R1.CS
R1.CP
R2.C
P
