2 Installation and commissioning
2.2.2 Connection of Extra Equipment to the Manipulator
50 3HAC021111-001 Revision: B
Connection of
Signal Lamp on
Upper Arm
(Option)
Location of Signal Lamp.
Signal lamp
R3.H1 +
R3.H2 -
