4 Repair
4.5.4. Replacement of balancing device (design 1)
3HAC026876-001 Revision: F298
© Copyright 2007-2010 ABB. All rights reserved.
Required equipment
Equipment
Spare part
no.
Art. no. Note
Balancing device See Spare
parts
Maintenance parts,
shaft
See Spare
parts
Maintenance parts,
cradle
See Spare
parts
Locking screw M16x60 quality 12.9 Gleitmo
For securing the lower arm.
Bearing grease 3HAB3537-1
Grease 3HAA1001-294
Grease pump - To lubricate spherical roller bearing.
Lifting tool (chain) 3HAC15556-1
Shackle 3HAC020997-001
Press tool,
balancing device
3HAC020902-001 For unloading and restoring the
balancing device.
Distance tool 3HAC030662-001
Dismantle and
mounting tool
3HAC028920-001 For dismantle and mounting of
shaft and bearings.
Hydraulic cylinder 3HAC11731-1 To be used with these tools:
• 3HAC028920-001
• 3HAC020902-001
Hydraulic pump,
80 MPa
3HAC13086-1 To be used with the hydraulic
cylinder 3HAC11731-1.
Standard toolkit - The content is defined in the
section Standard toolkit on page
409.
Loctite 577
Sikaflex 521FC
Continued
Continues on next page
