Note/illustrationAction
xx2100002624
Hang the holder with the bracket to the
desired place.
2
Hanging the front part of the FlexPendant holder with screws (Vertically)
Use this procedure to hang the front part of the FlexPendant holder to the desired
place.
Note/illustrationAction
xx2000002356
Remove the four screws.1
Separate the rear part from the FlexPend-
ant holder.
2
Clean the surface and make sure it is dry.3
Continues on next page
Product manual - OmniCore V250XT 63
3HAC073447-001 Revision: B
© Copyright 2020-2022 ABB. All rights reserved.
3 Installation and commissioning
3.4.3 Mounting the FlexPendant holder
Continued
