3.5 Electrical connections
3.5.1 Connectors on the OmniCore V250XT controller
General
The following section describes the connectors on the OmniCore V250XT controller.
CAUTION
Always inspect the connector for dirt or damage before connecting it to the
controller. Clean or replace any damaged parts.
Connectors
The following details the connection interface on the OmniCore V250XT controller.
HE GF
JI
K
D
C
B
A
xx2000001277
Continues on next page
