Emax E2.2-E4.2-E6.2 circuit-breakers | 2 - Transport and checking on receipt
7 | © 2013 ABB | 1SDH001000R0002 - L7804
2 - Transport and checking on receipt
Introduction
The Emax 2 circuit-breakers, on account of their weight, require special attention during
transport and handling.
They are distributed with following packages:
• single package for fixed circuit-breaker
• two packages for withdrawable circuit-breakers (one package for the fixed part and one
for the mobile part).
The following notes regard transport, handling and storage.
Weight of the circuit-breakers
with packaging
The following table specifies the weights of the circuit-breakers with packaging:
Fixed
Moving part of
withdrawable device
Fixed part of
withdrawable device
III IV Fs III IV Fs III IV Fs
E2.2 46 58 53 60 41 49
E4.2 63 77 67 81 57 69
E6.2 118 134 151 129 143 159 96 109 123
NOTE:
• weights are indicated with reference to the basic circuit-breakers including
protection release and its sensors, without terminals and without accessories.
• the weights of the fixed part of withdrawable circuit-breakers refer to the version
with horizontal rear terminals.
Transport of the packaged
circuit-breaker
Consult the table "Weight of the circuit-breakers with packaging" before proceeding with the
transport.
WARNING! Improper lifting can result in death, serious injury to persons and
damage to the equipment. Never lift a circuit-breaker and / or a fixed part
above other people.
IMPORTANT: The trained personnel in charge of handling and lifting must use
appropriate safety equipment.
