ABB SACE Emax 2 Series Installation, Operation And Maintenance Instructions

ABB | SACE Emax 2
Ekip Touch protection release | 6 - Menu
67 | © 2013 ABB | 1SDH001000R0002 - L7804
Components of the menus
The menus appear as follows:
A B
C
D
D
Advanced
S(V) Protection
Current-Voltage Protection (51V)
S2(V) Protection
Current-Voltage Protection (51V)
MCR Protection
Short circuit
D Protection
Directional (67)
IU Protection
Current unbalance (46)
Figure 73
The following table provides a description of the various areas of the menus:
Pos. Function
A It opens the higher level menu, or if there isn't one, the Menu page.
B It displays the name of the menu.
C
• It displays a list of the available submenus, the parameters that can be set,
and the commands that can be performed
• Depending on which it is selected, it opens a submenu, the Edit Parameters
page, or an information page, or performs a command.
D Scroll the list
NOTE: in the menus, under each parameter, the current value is shown.
Protections Menu
The following table illustrates the submenus and the protections associated to the menu
Protections, and the Ekip Touch releases in which they can be found.
IMPORTANT:
• Selecting a protection opens the list of parameters that can be set for the selected
protection.
• With Hi-Touch and G Hi-Touch releases, and the Dual Set function enabled (see
the Settings menu), the protections can be set according to two configurations
(Set A and Set B), of which the default configuration can be selected.
Protections
Release
• Set A
(1)
• Set B
(1)
Protection L
Touch
Hi-Touch
G-Touch
G
Hi-Touch
Protection S
Protection S2 - -
Protection I Touch G-Touch
Protection G Touch
(2)
G-Touch
(2)
Protection Gext
(3)
Touch G-Touch
(1)
Submenus available with Hi-Touch and G Hi-Touch releases, and the Dual Set function enabled (see the
Settings menu).
(2)
With Touch and G Touch releases, alternative protection to Gext, therefore available only without external
homopolar toroid or S.G.R. (see the menu Settings, Circuit-breaker, Earth protection).
(3)
Protection available with external homopolar toroid or S.G.R. (see the menu Settings, Circuit-breaker,
Earth protection), and alternative to RC protection (see the Advanced menu).

ABB SACE Emax 2 Series Specifications

General

Breaking capacity	Up to 150kA
Number of poles	3 or 4 poles
Communication protocols	Modbus, Profibus
Standards	IEC 60947-2
Type	Air circuit breaker
Mounting	Fixed, Withdrawable
