ABB | SACE Emax 2
130 | © 2013 ABB | 1SDH001000R0002 - L7804
Ekip Touch protection release | 15 - Measuring Measurements
15 - Measuring Measurements
Presentation
Measuring Measurements are available in all the models of releases of the Ekip TOUCH range
supplied with Ekip Measuring module or Ekip Measuring Pro.
The following is a list of the measurements:
Measurements Description
Instantaneous
voltages
Real Time measurements of the voltages
Instantaneous
powers
Real Time measurements of the active, reactive, apparent power
Trips List of the trips due to voltage, frequency, power
Maximum voltage
History of the maximum voltages recorded with an interval that can
be set
Minimum voltage
History of the minimum voltages recorded with an interval that can
be set
Maximum power
History of the maximum active powers recorded with an interval
that can be set
Average power
History of the average active powers recorded with an interval that
can be set
Power factor Real time measurement of the power factor
Instantaneous
frequency
Measurement of the line frequency
Energy meters Measurement of active, reactive, apparent energy
With the Ekip Measuring Pro module and Ekip Synchrocheck, a further set with of measurements
is activated:
Measurements Description
Synchrocheck
Measurements related to the function of synchronism between two
independent power supply systems.
