ABB tacteo KNX - Application - LED Function; Operating Mode

Description of application and parameters
Application "Function block RTC"
Product manual 2CKA001473B9482
│
126
11.5.138 Application - LED function
The application can be used to configure the button LEDs for the status or function display.
The following communication objects are available:
■
"Status LED"
■
"Day/night mode"
■
"Alarm"
■
"Scene storage"
The LEDs can light up in different colours and brightness levels. The LEDs can also flash for
alarm display and/or scene storage display.
Note
The parameters for application "LED function" can be called via general
parameters
and extended parameters .
11.5.138.1 Operating mode
Options: Status illumination
Function illumination
■
Status illumination:
– The button LEDs display the device status with different colours.
■
Function illumination:
– The button LEDs display the device functions with different colours.
The parameter is used to specify whether the RTC button LEDs display the current device
status or the selected device function with a colour.
If the operating mode "Status illumination" is selected, the LEDs have the 1-bit or 1-byte
communication object "Status LED". If a telegram is received via the status object, the LEDs
light up in the colour of the received value.
If operating mode "Function illumination" is selected, the colour for the configured button
function can be firmly set via parameter "Colour of function illumination".
