Commissioning
Product manual 2CKA001473B9482
│
27
7 Commissioning
7.1 Software
To start the device a physical address must be assigned first. The physical address is assigned
and the parameters are set with the Engineering Tool Software (ETS).
NOTE
The devices are products of the KNX system and meet KNX guidelines. Detailed
expert knowledge by means of KNX training sessions for a better understanding
is assumed.
7.1.1 Preparation
1. Connect a PC to the KNX bus line via the KNX interface (e.g. via the commissioning
interface / commissioning adapter 6149/21-500).
– The Engineering Tool Software must be installed on the PC (native application from
ETS 4.0).
2. Switch on the bus voltage.
7.1.2 Assigning a physical address
1
2
1. Press the programming button [1].
– All LEDs [2] light up red.
Fig. 19: Programming button
