Description of application and parameters
Application "Function block RTC"
Product manual 2CKA001473B9482
135
11.5.138.13 Colour of function illumination
Options: Off
Yellow (light)
Red/orange (heating)
Red
Violet (scene)
Blue (blind)
Green
White (neutral)
■
Off:
– The button LEDs are switched off.
■
Yellow - white:
– The button LEDs light up in the selected colour.
The parameter is used to specify the colour the associated function icons (RTC buttons) of the
device light up in.
The LEDs additionally serve for orientation, this means that the buttons can be recognized in
the dark. Alternatively, the LEDs can also be switched off, such as when the device is in a
sleeping area.
Note
The parameter is only adjustable if the "Operating mode" parameter is set on
"Function illumination".
