FCA/S 1.x.x.1 | 2CDC508134D0202 77
3.2.3.1.1 Description of the Fan Coil operating modes with valve drive, thermoelectric (PWM)
Control values overview
Functions of the output
A
B
C
D
General
- Overload


- Parallel operation

free

free
Valve drives allocated to the Fan Coil unit
- Thermoelectric (PWM)




- 1 control value/1 valve

free
free
free
- 2 control values/1 valve

free
free
free
- 2 control values/2 valves

free

free
Setting facilities for valve drives
- Thermoelectric (PWM)
- Separate heating/cooling




- Direction
OPEN/CLOSE
OPEN/CLOSE
OPEN/CLOSE
OPEN/CLOSE
 = Control value functions
- = Control value does not function
Valves independently usable
If the option Enabled as switch actuators is selected in the parameter window Enable output E...H, the
outputs A, B, C and D can be used independently.
The individual communication objects appear. The control value is connected to the outputs via group
addresses.
Output A
Output B
Output C
Output D
Fan EFG
Valves
Freely parameterizable




As switch
actuators
 = Control value functions
- = Control value does not function
