160
11.6.6.2 Object type/number
Options: A 1-bit object for input and output
Two 1-bit objects for input and output
Two 1-byte objects for input and output
■
A 1-bit object for input and output:
– When an On telegram is received via the "GFx: input_output" object, an adjustable
switch-off delay is started. After expiration of the switch-off delay, the "GFx:
input_output" object sends an Off telegram (1 bit).
■
Two 1-bit objects for input and output:
– When a switching telegram (On or Off) is received via the "GFx: input" object, an
adjustable switch-off delay is started. At the same time, a telegram with the same value
of the telegram received on the input (On or Off) is sent via object "GFx: output". After
expiration of the switch-off delay, the "GFx: output" object sends an Off telegram (1 bit).
■
Two 1-byte objects for input and output:
– When a value telegram is received via the "GFx: input" object, an adjustable switch-off
delay is started. At the same time, a telegram with the same value of the telegram (1
byte) received on the input is sent via object "GFx: output". After expiration of the
switch-off delay, the "GFx: output" object sends a telegram with value "0" (1 byte).
The parameter is used to fix the size and number of the communication objects for the
"Staircase lighting" application.
The switch-off delay of the staircase lighting is set via the "Switch-off delay" parameter.
11.6.6.3 Switch-off delay
Options: Setting option from 00:00:10 to 01:30:00 (hh:mm:ss)
The parameter is used to set the switch-off delay of the staircase lighting. The switch-off delay
can be set in steps of one second.
The start of the switch-off delay is dependent on the setting of the "Object type/number"
parameter. The parameter "Object type/number" also specifies whether an Off telegram (1 bit)
or a telegram with value "0" (1 byte) is sent after the expiry of the switch-off delay.
